FEATURES

• Rotary Vane Primer
• Controls are easy to operate from one location
• Engine on/off/start rotary switch
• Push button electric start with manual recoil back up
• 12V inlet/outlet socket
• Pressure indication, throttle control and choke control
• Pump pressure gauge and pump compound gauge
• Non return valve outlets
• Stainless Steel Frame

Typical performance @ 3 metres suction lift:

SPECIFICATIONS

Pump:
Type: Combination: Pressure/Volume
Intake: 4” (100mm) BSRT
Discharge: 70mm FI Double Lug
Volute Body And Head: Marine Grade Aluminium Alloy CC601 Heat-Treated
Impeller: Marine Grade Aluminium Alloy CC601 fully enclosed
Wear Rings: Long wearing PTFE, economical to replace
Shaft Seal: Spring-loaded mechanical
Priming: Dry sliding vane type with electric clutch. Fast and easy to use. Primes 3m in 10 secs, 7m in 30 secs.

Engine:
Engine Model No: Briggs and Stratton 386447
Type: Vanguard V-Twin air cooled overhead valve with Oil Cooler Heat Exchanger
Maximum output: 23HP (17.2kW) @ 3600 RPM 38.26 cu.
Displacement: 627CC, 4 cycle full pressure lubrication
Fuel Tank: Integral 10L
Battery: 12V VRLA Battery
Dry Weight: 87kg (incl battery)
Dimensions: 623mmL x 500mmW x 630mmH

Optional Extras: Round the Pump Proportioner, Wheel Kit
